WindO/I-NV4 User’s Manual 30-27
3 Analog I/O Modules
30
Expansion Modules
● Analog Output Module
Allocation of device address for the analog output module is shown below.
For details on the parameter setting values, refer to “ Analog Output Parameter Setting Values” on page 30-27.
Analog Output Parameter Setting Values
The parameter setting values are as follows.
■ Signal Type
If the setting value is outside the range, a parameter setting error will occur.
■ Data Type
If the setting value is 2 to 65,535, a parameter setting error will occur.
■ Min., Max.
The minimum and maximum values can be set only when Optional range is selected as Data Type. Set the
minimum and maximum values between -32,768 and 32,767.
Channel
Parameter R/W
FC6A-K2A1
FC6A-K2A4
FC6A-K4A1
FC6A-K4A4
No. Address Number Address Number
CH0
Analog output data R +0 +0
Analog output status R +1 +1
CH1
Analog output data R +2 +2
Analog output status R +3 +3
CH2
Analog output data R ― +4
Analog output status R ― +5
CH3
Analog output data R ― +6
Analog output status R ― +7
Setting Value Signal Type
0 Unused
1 0 to 10V DC
2 -10 to +10V DC
3 0 to 20mA DC
4 4 to 20mA DC
Setting Value Data Type
0 Binary data
1 Optional range
