3 Operation Log Settings Dialog Box
15-20 WindO/I-NV4 User’s Manual
Output Data File Name
The file name format is as follows.
File Name Value of Device Address_YYMMDD_hhmmss.CSV
■ Example 1
Result: The file name is "OPLOGA123_1309.CSV".
■ Example 2
Result: The file name is "IDEC123_130915_233050.CSV".
File Name: The text entered in File Name or the text entered according to the value of the device
address set by Specify File Name by Value of Device Address
Value of Device Address: The lower 3 digits of the value of the device address configured by Add Device
Address data to File Name
YYMMDD: The year, month, and day of the month set on Add Time Stamp
hhmmss: The hour, minute, and second of the time configured on Add Time Stamp
Item Setting
File Name OPLOGA
Add value of Device Address to File
Name
(File Name Device Address) is
LDR200
LDR200 value: 123
Add Time Stamp YY+MM Date when data was output: September 2013
Item Setting
Specify File Name by Value of Device
Address
(File Name Device Address) is
LDR100
Text to set is "IDEC"
LDR100 value: 4944 (Hex)
LDR101 value: 4543 (Hex)
LDR102 value: 0000 (Hex)
Add value of Device Address to File
Name
(File Name Device Address) is
LDR200
LDR200 value: 123
Add Time Stamp YY+MM+DD+HH+MM+SS
Date and time when data was output:
September 15 2013 at 23:30:50
