WindO/I-NV4 User’s Manual 17-15
4 Using the Data
17
Preventive Maintenance Function
7 Select the Report when Operation Time has reached or exceeded Threshold level check box.
8 Select the type of data for the threshold.
If you select Value, specify the threshold as a constant.
If you select Device Address, specify the threshold as a value of device address.
9 Configure Threshold for level 1.
When you select Value as the threshold data type, specify the threshold as a constant. The range for the constant
that can be set varies based on the data type.
When you select Device Address as the threshold data type, specify the threshold as a value of device address. Click
to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address
Settings” on page 2-70.
10
Configure Report Device Address for level 1.
Specify the bit device or the bit number of the word device for reporting when the threshold is reached or exceeded.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
You can only specify an internal device.
11
Click OK to close the Individual Settings dialog box.
You are returned to the Preventive Maintenance Settings dialog box.
12
Click OK.
The Preventive Maintenance Settings dialog box closes.
13
On the Configuration tab, in the System Setup group, click Alarm Log.
The Alarm Log Settings dialog box is displayed.
