WindO/I-NV4 User’s Manual 3-15

5 User Communication

Communication

Repeat steps

through

to set all the data for the transmission command.

Click OK.

The transmission command configured in Command List and Data List on Project Settings dialog box is displayed.

• The data is displayed in Data List in the order they were set. To change the order of data, select data,

and then click Up or Down to shift it.

• Click Expand Data List to hide Type, Trigger Condition and Detail, the number of the data displayed

in Data List will increase.
