3 Uploading
24-22 WindO/I-NV4 User’s Manual
3 Check the project data details, and then click Upload.
If there is a project file with the same file name in the upload folder, an overwrite confirmation message is displayed.
• Click Yes to start uploading the project data.
• Click Cancel to stop uploading the project data.
When finished uploading, a completion message is displayed.
■ Project Name
The project is saved with the currently displayed name. To change the project name, enter a new name for the file.
The maximum number is 50 characters.
■ Location
The uploaded project file is saved to the currently displayed location. To change the location of the saved file,
click . The Browse folders dialog box is displayed. Select a location, and then click OK.
4 Click OK.
5 Click Close on the Upload dialog box.
A confirmation message to open the project is displayed.
6 Click OK.
The uploaded project opens.
This concludes uploading of project data.
You cannot use the following characters in the project name.
" * / : < > ? \ |
If a password has been configured for the project data, the Enter Password screen will be displayed. Enter
the password for projects created with WindO/I-NV4 Ver. 1.11.4 or earlier using only 4 to 15 uppercase
letters and numbers.
The password to enter varies based on the check box setting of the Use Password to open a Project
found under the Options tab in the Security dialog box.
When this check box is selected, enter the password for Use Password to open a Project.
When this check box is cleared, enter the password for the user account assigned to the Administrator
security group.
For details, refer to Chapter 23 “User Accounts and the Security Function” on page 23-1.
For details on reading project data saved on an external memory device using WindO/I-NV4, refer to
Chapter 31 “Uploading” on page 31-9.
