4 E-mail Function

28-60 WindO/I-NV4 User’s Manual

● Attach Files Dialog Box

Files attached to an e-mail is configured in the Attach Files dialog box.

■ Screenshot

Select this check box to attach a screenshot of the current screen to an e-mail.

The file format is JPEG and the file name becomes "Image.JPG".

■ Alarm Log Files

Select this check box to attach a specified alarm log data to an e-mail.

The file format is CSV and the file name becomes "ALMLOG.CSV".

Specifies the output format and the range of the alarm log data.

Output Format: Specifies the items of the alarm log data attached to an e-mail.

Output Channel Number, Message, Occurrence Time, Recovery Time and Confirmaton Time:

The output data is the same format as the Alarm Log function batch outputs to the

external memory device. For details, refer to Chapter 13 “Batch” on page 13-38.

Output Channel Number, Message, State and Time:

The output data is the same format as the Alarm Log function outputs to the external

memory device in real time. For details, refer to Chapter 13 “Real Time” on page 13-39.

Range of Blocks: Specifies the range of block numbers that will output in the collected alarm log data.

All: Outputs the data for all blocks.

Specify block number: Outputs only the data for the specified blocks.

Individual block numbers can be specified by separating the num-

bers with “,”, continuous regions can be specified with “-”.

Example: When the number of blocks is 6, enter the following.

To specify blocks 1 to 3: 1-3

To specify blocks 1, 3, 6: 1, 3, 6

To specify blocks 1, 4 to 6:1, 4-6

Specify a period of time: Select this check box to specify the period of alarm log output data. Outputs the specified

period of the alarm log data after the Trigger Condition is satisfied.

Specify the maximum number of items:

Select this check box to specify the maximum amount of alarm log output data. Outputs the

specified number of the alarm log data after the Trigger Condition is satisfied.

When the Specify a period of time check box and the Specify the maximum number of items check

box are selected, the output range is until either is satisfied.
