1 Project Transfer Function

29-14 WindO/I-NV4 User’s Manual

9 Press COPY.

A process confirmation message is displayed.

Press YES.

The project upload starts.

When the upload finishes, the results are displayed.

Press Ack to close the results screen.

You are returned to the Top Page of System Mode.

Main

---

File

Manager

---

▲

DEL

▼

▲

RELOAD

ENT COPY

DIRECTION

▲

FILTER

ALL

FILTERS

DRIVE:

MICRO/I

FORMAT

DRIVE:

SD card

FORMAT

DIR

MICROI.ZNV

YES NO

Copy This File ?

MICROI.ZNV

MICROI.ZNV is shown on the confirmation message, but the project file name after uploading is “Project

name + Extension (.znv)”.

Upload MICRO/I Project

Function

The following function completed

Result

Ack
