1 Bit Devices
33-4 WindO/I-NV4 User’s Manual
Device
Address
Function/Part
HG2J
-7U
HG5G/
4G/3G/
2G-V
HG4G/
3G,
HG2G-
5F
HG2G
-5T,
HG1G
/1P
LSM57
When the value of this bit changes from 0 to 1, get the current time
from the SNTP server.
The acquired current time is written to the MICRO/I internal clock
and stored in the MICRO/I internal current time data (LSD13 to 19).
Yes No No No
LSM58 Value is 1 while there is a connection with an FTP client. Yes Yes Yes Yes
LSM59
If the value of this bit changes from 0 to 1, the connections for the
FTP client and the MICRO/I is forcibly disconnected.
When it becomes 1 value does not become 0 until the MICRO/I is
reset or 0 is written.
Yes Yes Yes Yes
LSM60, 61 Reserved
LSM62
When the value of this bit changes to 1, the POWER LED is turned off
(unlit). When changes to 1, the POWER LED turns ON (lit in green).
After the MICRO/I is reset, value becomes 1 when operation starts.
Yes Yes Yes Yes
LSM63 Reserved
LSM64 Value is 1 while transferring a file. Yes Yes Yes Yes
LSM65
When the value of this bit changes from 0 to 1, file transfers are
prohibited. When the value of this bit changes to 1 during a file
transfer, the file transfer is completed, and then file transfers are
prohibited from the next transfer.
Yes Yes Yes Yes
LSM66 Reserved
LSM67
When the value of this bit changes from 0 to 1, copying and moving
subfolders and files included in subfolders is prohibited when
transferring files from external memory to external memory. When
the value of this bit changes to 1 during a file transfer, the file
transfer is completed, and then copying and moving subfolders and
files included in subfolders is prohibited.
Yes Yes Yes Yes
LSM68, 69 Reserved
LSM70
When the value of this bit changes from 0 to 1, BACnet
communication is enabled.
When the value of this bit changes from 1 to 0, BACnet
communication is prohibited.
When the BACnet communication is stopped by error and restarts
the BACnet communication, set 0 to the value of LSM70, and then
set 1 to the value of LSM70 after the status of the BACnet
communication is stopped. The status of the BACnet communication
can be checked with the value of LSD260.
No Yes No No
LSM71
When the value of this bit changes from 0 to 1, MICRO/I stops
updating the display of the Data Log Display. When the value of this
bit changes from 1 to 0, MICRO/I restarts updating the display.
Yes Yes Yes Yes
LSM72 to 74 Reserved
LSM75
When the value of this bit changes from 0 to 1, MICRO/I cancels
sending all the social media messages in "Waiting" status. Even if the
value of LSM76 is 1, this function can be executed.
Yes No No No
LSM76
While the value of this bit is 1, MICRO/I pauses sending of all the
social media messages in "Waiting" status. If the value changes from
0 to 1 while sending a social media message is in progress, MICRO/I
will pause after such social media message has been sent.
Yes No No No
LSM77
When the value changes from 0 to 1, the values of SSID, password,
IP address, subnet mask, default gateway and port number for
maintenance communication (LSD292 to 356) of the wireless LAN
are written to the MICRO/I, then MICRO/I automatically resets. After
the MICRO/I is reset, value becomes 0 when operation starts.
Yes No No No
LSM78
When the value of this bit changes from 0 to 1, start the wireless
LAN connection.
When the value of this bit changes from 0 to 1, stop the wireless LAN
connection.
The status of the wireless LAN connection can be checked with the
value of LSD366.
Yes No No No
LSM79 to 95 Reserved
