WindO/I-NV4 User’s Manual 35-11
1 HG2J-7U
35
MICRO/I Specifications
● Cautions for using the HG2J-7U connected to a personal computer
When connecting the HG2J-7U to a personal computer via the USB Interfaces, the HG2J-7U or the personal computer
may break down depending on the conditions of the personal computer. Make sure of the following cautions, in order
to prevent an accident.
• If the personal computer has a 3-pin power plug or power plug with a ground lead type, make sure to use a plug
socket including a ground input electrode or ground the earth lead, respectively.
• If the personal computer has a 2-pin power plug without ground lead, follow the procedure below when connect
the HG2J-7U to the personal computer.
(1) Pull out the power plug of the personal computer from the AC outlet.
(2) Connect the HG2J-7U to the personal computer.
(3) Insert the power plug of the personal computer into the AC outlet.
●
Recommended Tools
Tool Name Model Number (Order Number) Manufacturer
Flat blade screwdriver
Normal type SDS 0.4×2.5×75 (9009030000) Weidmüller
With insulated cover
S3TL-D04-25-75 IDEC
SDIS 0.4×2.5×75 (9008370000) Weidmüller
Crimping tool
S3TL-CR06D IDEC
PZ6/5 (90011460000) Weidmüller
Stripping tool
S3TL-ST06 IDEC
STRIPAX(9005000000) Weidmüller
To Next Page
