4 HG2G-5T, HG1G

35-62 WindO/I-NV4 User’s Manual

■ HG1G

Unit: mm

Depending on the type of connection cable used the dimensions shown above will change.

The dimensions given here are representative values and are intended for reference only.

102

34.5

27.8

128

117

Panel surface
