WindO/I-NV4 User’s Manual 35-75

5 HG1P

MICRO/I Specifications

■ EMC Specifications

Radiated Emission

Class A : 10m

•IEC 61000-6-4 Class A

40dBμV/m quasi-peak (30M to 230MHz)

47dBμV/m quasi-peak (230M to 1GHz)

•FCC Class A

39dBμV/m quasi-peak (30M to 88MHz)

43.5dBμV/m quasi-peak (88M to 216MHz)

46.4dBμV/m quasi-peak (216M to 960MHz)

49.5dBμV/m quasi-peak (960M to 1GHz)

Electrostatic Discharge

Contact : ±4kV

Air : ±8kV

Electromagnetic Field

10V/m (80M to 1.0GHz)

3V/m (1.4G to 2.0GHz)

1V/m (2.0G to 2.7GHz)

80% AM (1kHz)

Fast Transient Burst

Power : ±2kV

Communication cable : ±1kV

Surge Immunity

±500V (+24V and 0V)

±1kV (+24V and FE, 0V and FE)

Conducted Radio

Frequency Immunity

3V (Power, Communication cable)

(150k to 80MHz)

80% AM (1kHz)
