WindO/I-NV4 User’s Manual 3-81
5 User Communication
3
Communication
Receive command: Command Settings dialog box settings
Operation for receive command
1 When data transmission of the transmission command is completed, the value of LM101 changes to 1, and since the
same device address is specified for the trigger condition user communication becomes ready for receiving.
2 Data is transmitted from the external device and the transmitted data is received and processed.
The receive data is as follows.
Since a value of 100 is written to LDR100 at the time of transmission, the data is stored in device address LDR220,
which corresponds to an offset of +100 from LDR120.
• When data reception is successfully completed, the Completed Device Address LM102 changes to 1.
• When the value of each bit of address+0 of Status Device Address LDR130 is 0, reception is completed without an
error.
Item Setting
Type RXD
Trigger Condition While ON, Device Address: LM101
Completed Device Address LM102
Not Clear Completed Device Address
automatically
No
Status Device Address LDR130
Receiving Time Out 0 (No Receive Time Out)
Comment RXD command
Command
Data Settings dialog box settings
Constant
(Hexadecimal)
'02'
Constant
(Character)
"D"
Device Address
Conversion Type: ASCII to Hexadecimal,
Number of bytes: 4, Words: 1
Device Address: LDR120, Reference Device Address: LDR100
Constant
(Hexadecimal)
'0D'
D
(44h)
3
(33h)
4
(34h)
1
(31h)
STX
(02h)
2
(32h)
CR
(0Dh)
Receive data:
Constant
(Hexadecimal)
Constant
(Character)
Device Address
Command settings:
Constant
(Hexadecimal)
0000LDR120:
0000LDR121:
1234hLDR220:
Value of Device Address
LDR230=100
