WindO/I-NV4 User’s Manual 3-147

7 BACnet Communication

Communication

System_Status

Indicates the physical status and logical status of the MICRO/I.

System_Status of the MICRO/I is fixed as OPERATIONAL.

Firmware_Revision

This property is set with the System Software Version of the MICRO/I.

Application_Software_Version

Set information about the application, such as the modification date of the created project data, as a fixed string with

WindO/I-NV4.

Protocol_Services_Supported

This property represents the types of services that are supported by the MICRO/I.

Protocol_Object_Types_Supported

This property represents the types of objects that are supported by the MICRO/I.

Object_List

This property represents the list of created objects.

Parameter Value

OPERATIONAL 0

OPERATIONAL_READ_ONLY 1

DOWNLOAD_REQUIRED 2

DOWNLOAD_IN_PROGRESS 3

NON_OPERATIONAL 4

BACKUP_IN_PROGRESS 5
