3 Project Settings Dialog Box

4-54 WindO/I-NV4 User’s Manual

Number of external device limitations

• The number of external devices that can be connected to External Device Communication 1 to External

Device Communication 4 is a total of 32 external devices.

• The number of external devices that can be set varies based on the communication interface.

Communication Interface Number of External Devices

Serial Interface (Connection: 1:1 communication) 1

Serial Interface (Connection: 1:N communication) 31 max.

Ethernet Interface 32 max.
