WindO/I-NV4 User’s Manual 4-67
3 Project Settings Dialog Box
4
Project Settings
■ Use Custom Web Page
Select this check box to access the Custom Web Page saved in the external memory device of MICRO/I from a web
browser terminal. For details, refer to Chapter 28 “1.6 Custom Web Page” on page 28-12.
■ Execution Interval (msec)
Specifies the interval (0 to 5,000 ms) for the MICRO/I to return data. The load that the remote control function and
the remote monitoring function place on MICRO/I operation can be reduced by increasing this value. However, the
display update speed in the web browser will become slower.
■ Port Number
Specifies the TCP port number to use for the Web Server function (0 to 65,535).
■ Default Showing Page
Select the web page to display first when accessing the MICRO/I from a web browser terminal from the following.
System Information, Remote Monitor, Remote Control
In (Custom Web Page), the Custom Web page file name is displayed in Web Page Editor of the Project window.
This option can only be set when Use System Web Page or Use Custom Web Page is selected.
Regarding TCP port number of MICRO/I, note the following points.
The numbers that cannot be used: • 2539: Maintenance communication (Data Transfer)
• 2538: For pass-through
• 2101: For FC4A Series MicroSmart direct connection pass-through
Duplicate numbers cannot be configured in the following functions:
• Maintenance communication
( refer to “Port Number” on page 4-41)
• Web server function
• FTP server function ( refer to “Port Number” on page 4-68)
• TCP Server is selected for the User Communication
( refer to “Port No.” on page 4-43)
• Modbus as Manufacture and Modbus TCP Server as
Communication Driver are selected on the Communication
Driver tab
( refer to the WindO/I-NV4 External Device Setup Manual)
• YASKAWA Electric as Manufacture and MP2000(Ethernet) as
Communication Driver are selected on the Communication
Driver tab
( refer to the WindO/I-NV4 External Device Setup Manual)
To Next Page
