4 Project Restrictions

4-84 WindO/I-NV4 User’s Manual

■ E-mail Settings, Social Media Settings

The total number of external device addresses can be used in the E-mail Settings and the Social Media Settings is

255.

■ File Transfer Settings (FTP client function)

A maximum of 240 external device addresses can be used in the File Transfer settings.

If the same device address is used in multiple device address settings, the number of used device addresses

is counted as 1. It is not counted as 1 device address per device address setting.
