WindO/I-NV4 User’s Manual 2-21
1 WindO/I-NV4 Specifications
2
WindO/I-NV4 Features & Basic Operations
● Saving pictures in Picture Manager
This section describes how to save drawing objects in Picture Manager. Saved pictures can be used for part diagrams
and drawings.
Saving image files
1 Click Import in Picture Manager.
The Open dialog box is displayed.
2 Specify the image file, and then click Open.
When managing pictures by category, create a new category, and select it. To create a category, click
Configure, and then click
(New Category) on the Category dialog box. For details, refer to “Category
Dialog Box” on page 2-31.
Click Options to Apply Dithering or Color Exchange. For details, refer to “Open Dialog Box” on page 2-
30.
To Next Page
