2 Multi-State Lamp
9-20 WindO/I-NV4 User’s Manual
Example 2: Bit Number is selected. The bits of trigger device address D0 and the OFF state are
allocated to the following pictures.
Switches the picture to display according to the status of the bits.
Value: Switches the drawing object displayed, according to the value of the device address.
Example 3: Value is selected. The value assigned to the trigger device address D0 are allocated to the
following pictures and the OFF state is None.
Switches the picture to display according to the value of the device address.
Example 4: Value is selected. The values assigned in trigger device address D0 and the OFF state are
allocated to the following pictures.
Switches the picture to display according to the value of the device address.
bit15 bit0bit3
Value of
Trigger Device Address D0
State:
0
State:
1
State:
2
OFF
OFF
Display picture
for bit 0
Display picture
for bit 1
Display picture
for bit 2
Display picture
for OFF state
Display picture
for bit 1
Display picture
for bit 2
0001 0010 0100
1000
1110
1100
State:
0
State:
1
State:
1
State:
2
State:
2
Picture to display
Bit state of
Trigger Device Address D0
Action
If multiple bits are 1,
display the picture for the
lowest order bit.
If all bits in the device address are 0 or if
a bit with no associated picture becomes
1, display the picture for OFF state.
012
Value of
Trigger Device Address D0
State:
2
State:
1
State:
0
(None)
OFF
Display picture for 0 Display picture for 1 Display picture for 2
No picture
0 1 2 3
State:
0
State:
1
State:
2
Picture to display
Value of
Trigger Device Address D0
Action
If the value of device
address has no picture
associated with it, display
nothing.
OFF
012
Value of
Trigger Device Address D0
State:
2
State:
1
State:
0
OFF
Display picture
for 0
Display picture
for 1
Display picture
for 2
Display picture
for OFF state
0 1 2 3
State:
0
State:
1
State:
2
Picture to display
Value of
Trigger Device Address D0
Action
If the value of device
address has no picture
associated with it, display
the picture for OFF state.
