2 Multi-State Lamp

9-24 WindO/I-NV4 User’s Manual

■ Align Text Vertical

Selects text alignment in the vertical direction.

Top, Center, Bottom

This option can only be configured when Left, Center, or Right is selected for Align Text Horizontal. If Center-

Left is selected for Align Text Horizontal, Center-Top is set as this option.

For details, refer to Appendix “5 Text Alignment” on page A-7.

■ Use Text Manager

Select this check box if using the text registered in Text Manager for text display.
