1 WindO/I-NV4 Specifications
2-36 WindO/I-NV4 User’s Manual
Picture Name Setting Dialog Box
Specifies a name for images saved in Picture Manager.
â– (Image)
An image of the picture is displayed.
â– Picture Name
Enter a name for the picture. The maximum number is 256 characters.
â– Apply Dithering
Select this check box to perform dithering (error diffusion method) on images.
This function enables some images with tonal gradations and photo-like pictures to be rendered more beautifully
when they are saved.
â– Color Exchange
Select this check box to convert the color of the picture.
(Image)
You cannot use the following characters in the picture name.
HG2J-7U: " # $ & ' ( ) * / : ; < > ? \ ` | ~
HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P: " * / : < > ? \ |
From: Specifies color before conversion. Click this button to display the Color Settings dialog box. Specify the color,
and then click OK.
to: Selects the color after conversion (color: 256 colors, monochrome: 16 shades). Click this button to display the
Color Palette. Select a color from the Color Palette. Transparent Color can also be selected.
To make the background color of the picture saved from Symbol Factory transparent, set From and
Background Color in (Symbol Options) to R: 254, G: 254, B: 254.
