WindO/I-NV4 User’s Manual Preface-6
Abbreviations, Generic Terms, and Terminology Used in this Manual
Abbreviations, Generic Terms, and Terminology Used in this Manual
Item Description
HG2J-7U The name is short for MICRO/I HG2J-7UT22TF-B.
HG5G-V The name is short for MICRO/I HG5G-VFXT22MF-B.
HG4G-V The name is short for MICRO/I HG4G-VCXT22MF-B.
HG4G The name is short for MICRO/I HG4G-CJT22*F-B.
HG3G-V The name is short for MICRO/I HG3G-V*XT22MF-*.
HG3G The name is short for MICRO/I HG3G-*JT22*F-*.
HG2G-V The name is short for MICRO/I HG2G-V5FT22TF-*.
HG2G-5F The name is short for MICRO/I HG2G-5FT22TF-*.
HG2G-5T The name is short for MICRO/I HG2G-5T*22TF-*.
HG1G The name is short for MICRO/I HG1G-4VT22TF-*.
HG1P The name is short for MICRO/I HG1P-ST32*.
HG5G/4G/3G/2G-V The format used to refer to HG5G-V, HG4G-V, HG3G-V and HG2G-V.
HG5G/4G/3G-V The format used to refer to HG5G-V, HG4G-V and HG3G-V.
HG4G/3G The format used to refer to HG4G and HG3G. HG4G-V and HG3G-V is not included.
HG2G-5F/-5T The format used to refer to HG2G-5F and HG2G-5T.
HG1G/1P The format used to refer to HG1G and HG1P.
MICRO/I
Generic term used to refer to the HG2J-7U, HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T,
HG1G/1P.
External Device
Generic term used to refer to a PLC or micro computer that is connected to and
communicates with the MICRO/I.
Device Address
Memory that is capable of storing values in unit of bits or words loaded on the MICRO/I
and external device.
System Area
Device address area that is pre-allocated for exchanging screen management, error
information, and clock data between the MICRO/I and an external device.
Device Link Communication
A communication method that performs communication with the external device
according to the setting of the screen and without a program.
DM Link Communication
A communication method that reads to or writes value to external devices using the
MICRO/I's dedicated DM Link memory.
User Communication
A communication method which performs communication with external devices such as
barcode readers and inverters.
External Device Communication Generic term used to refer to Device Link Communication and DM Link Communication.
Sub Host Communication
A communication method that performs communication with external device according
to the set device address list and without a program.
BACnet Communication
A communication method for building management systems such as air conditioning,
lighting and crime prevention.
O/I Link
A connection format that enables connections of up to 16 units of MICRO/I with high-
speed communication of 115,200bps.
O/I Link Master The MICRO/I unit that is directly connected to external device on the O/I Link network.
O/I Link Slave
The MICRO/I units that are not directly connected to external device on the O/I Link
network.
WindO/I-NV4 Integrated configuration software application for creating projects of the MICRO/I.
Operating System Software used to manage and control system software. Only HG2J-7U supports the update.
System Software Software required for operating MICRO/I.
Project
Data including image data required for operating the MICRO/I, which is created with
WindO/I-NV4.
Manager
WindO/I-NV4 provides tools to manage pictures, text and script etc. With the Managers,
you can create and manage them in your project.
Setup Generic term used to refer to the common settings in the project.
