2 Word Write Command
12-10 WindO/I-NV4 User’s Manual
■ Set
■ Move
■ Momentary
■ Add, Sub, Multi, Div, Mod, OR, AND, XOR
Writes a fixed value to a word device when the
trigger condition is satisfied.
State of condition
Data written
Write
Action
Write
Value
Value
Condition Condition Condition Condition
SatisfiedSatisfiedSatisfiedNot satisfiedNot satisfiedNot satisfied SatisfiedSatisfiedSatisfied
Not satisfiedNot satisfiedNot satisfied
Writes the value of source device address to the
destination word device when the trigger
condition is satisfied.
State of condition
Data written
Write
Action
Write
Value in
device address
Value in
device address
Condition Condition Condition Condition
SatisfiedSatisfiedSatisfiedNot satisfiedNot satisfiedNot satisfied SatisfiedSatisfiedSatisfied
Not satisfiedNot satisfiedNot satisfied
Writes a fixed value of ON Data to a word device
when the trigger condition is satisfied.
Writes a fixed value of OFF Data to a word device
when the trigger condition is no longer satisfied.
State of condition
Data written
Write
Action
OFF Data
Write
ON Data
Write
OFF Data
Write
ON Data
Condition Condition Condition Condition
SatisfiedSatisfiedSatisfiedNot satisfiedNot satisfiedNot satisfied SatisfiedSatisfiedSatisfied
Not satisfiedNot satisfiedNot satisfied
Performs arithmetic on the value of source device
address and a fixed value, or a value of device
address and writes the result to a word device
when the trigger condition is satisfied.
Example: Add (Addition)
When the trigger condition is satisfied,
the value in the Source 1 is added to
the value in Source 2 and the result is
written to the word device.
State of condition
Data written
Action
Result
Arithmetic operation
↓
Write
Result
Arithmetic operation
↓
Write
Condition Condition Condition Condition
Satisfied
Satisfied
SatisfiedNot satisfied
Not satisfied
Not satisfied
Satisfied
Satisfied
Satisfied
Not satisfied
Not satisfied
Not satisfied
State of condition
Data written
Action
Result Result
Addition
↓
Write
Addition
↓
Write
Condition Condition Condition Condition
SatisfiedSatisfiedSatisfiedNot satisfiedNot satisfiedNot satisfied SatisfiedSatisfiedSatisfied
Not satisfiedNot satisfiedNot satisfied
