Mitsubishi FR-A800

(D) Operation command and frequency command
314
PARAMETERS
• To switch between the Network operation mode and the External operation mode
1) Set Pr.79="0" (initial value) or "2, "6" or "7". (When Pr.79 ="7" and the X12 (MRS) signal is ON, the operation mode can
be switched.)
2) Set Pr.340 Communication startup mode selection ="0" (initial value), "1" or "2".
3) Set "66" in one of Pr.178 to Pr.189 to assign the NET-External operation switching signal (X66) to a terminal.
4) When the X66 signal is ON, Network operation mode is selected. When the X66 signal is OFF, the External operation
mode is selected.
 When "Pr.550 NET mode operation command source selection = "0" (communication option control source)" and no communication option is
connected, the External operation mode is selected.
 When the X16 signal is OFF, the PU operation mode is selected. Also, when the X65 signal is assigned, the operation mode follows the ON/OFF
state of the X65 signal.
NOTE
• The priority of Pr.79 and Pr.340 and signals is Pr.79 > X12 > X66 > X65 > X16 > Pr.340.
• Changing the terminal assignment using Pr.178 to Pr.189 (input terminal function selection) may affect the other
functions. Set parameters after confirming the function of each terminal.
???????
Parameters referred to
Pr.15 Jog frequency page 327
Pr.4 to Pr.6, Pr.24 to 27, Pr.232 to Pr.239 multi-speed operation page 328
Pr.75 Reset selection/disconnected PU detection/PU stop selection page 259
Pr.161 Frequency setting/key lock operation selection page 263
Pr.178 to Pr.182 (input terminal function selection) page 430
Pr.190 to Pr.196 (output terminal function selection) page 384
Pr.340 Communication startup mode selection page 315
Pr.550 NET mode operation command source selection page 316
Pr.340
setting
Pr.79
setting
X66 signal state
REMARKS
ON (NET) OFF (External)
0
(initial value),
1, 2
0 (initial value)
NET operation mode External operation mode 
1 PU operation mode PU operation mode fixed
2
NET operation mode External operation mode Switching to PU operation mode is disabled.
3, 4 External/PU combined operation mode External/PU combined operation mode fixed
6
NET operation mode External operation mode
Switching between operation modes is
enabled while running.
7
X12 (MRS)
ON
NET operation mode External operation mode
Output is shutoff in the External operation
mode.
X12 (MRS)
OFF
External operation mode
The operation mode is forcibly switched to the
External operation mode.
