Mitsubishi FR-A800

(M) Monitor display and monitor output signal
PARAMETERS
361
5
GROUP
M
Orientation
status

1 22 H16 40222
Displays values only when orientation
control is enabled. (Voltage monitor
will appear when FR-A8AP is not
connected.) (Refer to page 488)
Actual operation
time

1 h 23 H17 40223
Displays the cumulative time since
the inverter began running.
The number of times the monitor
value exceeded 65535 h can be
checked with Pr.564
This can be cleared with Pr.171.
(Refer to page 367)
Motor load factor 0.1% 24 H18 40224
Displays the output current value as a
percentage, considering the inverter
rated current value as 100%.
Monitor value = output current
monitor value / inverter rated current
 100 [%]
Cumulative power

0.01 kWh/0.1
kWh

25 H19 40225
Displays the cumulative energy
based on the output power monitor.
This can be cleared with Pr.170.
(Refer to page 367.)
Position command 1 26 H1A 40226 
Displays the position command
(decimal) before the electronic gear is
set.

Position command
(upper digits)
1 27 H1B 40227 
Current position 1 28 H1C 40228  Displays the value of the position
feedback pulse after converting it into
the number of pulses before the
electronic gear is set.

Current position
(upper digits)
1 29 H1D 40229 
Droop pulse 1 30 H1E 40230 
Displays the droop pulse before the
electronic gear.

Droop pulse (upper
digits)
1 31 H1F 40231 
Torque command 0.1% 32 H20 40232 
Displays the torque command value
obtained from the vector control
results.
Torque current
command
0.1% 33 H21 40233 
Displays the commanded current for
the torque.
Motor output
0.01 kW/0.1
kW

34 H22 40234
Multiplies the output torque at that
time with the motor speed, and
displays the machine output for the
motor shaft end.
Feedback pulse
 — 35 H23 40235
Display the number of pulses fed
back from the encoder during one
sampling (also displays during stop).
(Voltage monitor will appear when
FR-A8AP is not connected.)
The sampling time varies with the
Pr.369 Number of encoder pulses
setting.
1050 or less: 1 s
1051 to 2100: 0.5 s
2101 to 4096: 0.25 s
Trace status 1 38 H26 40238
Displays the trace status. (Refer to
page 547)
PLC function user
monitor 1
According to
the SD1215
setting
40 H28 40240
Displays the arbitrary monitoring item
using the PLC function.
Displays the following special register
values.
SD1216: Displays in No.40
SD1217: Displays in No.41
SD1218: Displays in No.42
(Refer to the PLC Function
Programming Manual.)
PLC function user
monitor 2
41 H29 40241
PLC function user
monitor 3
42 H2A 40242
Types of
monitor
Unit
Pr.52,
Pr.774 to Pr.776,
Pr.992
RS-485
communication
dedicated
monitor
(hexadecimal)
Modbus-
RTU
real
time
monitor
Minus (-)
display
Description
