(M) Monitor display and monitor output signal
362
PARAMETERS
Station number
(RS-485 terminals)
1 43 H2B 40243
Displays which station number (0 to
31) can currently be used for
communication from the RS-485
terminal block.
Station number
(PU)
1 44 H2C 40244
Displays which station number (0 to
31) can currently be used for
communication from the PU
connector.
Station number
(CC-Link)
1 45 H2D 40245
Displays which station number (0 to
31) can currently be used for CC-Link
communication.
Displays "0" when the FR-A8NC is
not connected.
Energy saving
effect
Changeable
by parameter
setting.
50 H32 40250
Displays the energy saving effect
monitor.
Conversion to power saving, average
power saving, price display, and
percentage display can be done
using parameters.
(Refer to page 379.)
Cumulative energy
saving
51 H33 40251
PID set point 0.1% 52 H34 40252
Displays the set point, measured
value, and deviation under PID
control.
(Refer to page 510)
PID measured
value
0.1% 53 H35 40253
PID deviation 0.1% 54 H36 40254 
Input terminal
status
—
55

H0F 40215
Displays input terminal ON/OFF state
of the inverter. (Refer to page 366 for
DU display.)
Output terminal
status
—H10
 40216
Displays output terminal ON/OFF
state of the inverter. (Refer to page
366 for DU display.)
Option input
terminal status

—56 — —
Displays input terminal ON/OFF state
of the digital input option (FR-A8AX)
on the DU. (Refer to
page 366 for
details.)
Option output
terminal status

—57 — —
Displays output terminal ON/OFF
state of the digital output option (FR-
A8AY) and the relay output option
(FR-A8AR) on the DU. (Refer to
page
366
for details.)
Option input
terminal status 1
(for
communication)

—— H3A 40258
Input terminal X0 to X15 ON/OFF
state of the digital input option (FR-
A8AX) can be monitored via RS-485
communication and the
communication option.
Option input
terminal status 2
(for
communication)

—— H3B 40259
Input terminal DY ON/OFF state of
the digital input option (FR-A8AX) can
be monitored via RS-485
communication and the
communication option.
Option output
terminal status 1
(for
communication)

—— H3C 40260
Output terminal ON/OFF state of the
digital output option (FR-A8AY) and
relay output option (FR-A8AR) can be
monitored via RS-485 communication
and the communication option.
Motor thermal load
factor
0.1% 61 H3D 40261
Displays the accumulated heat value
of the motor thermal O/L relay.
The motor overload trip (E.THM)
occurs at 100%.
Inverter thermal
load factor
0.1% 62 H3E 40262
Displays the accumulated heat value
of the inverter thermal O/L relay.
The inverter overload trip (E.THT)
occurs at 100%.
Types of
monitor
Unit
Pr.52,
Pr.774 to Pr.776,
Pr.992
RS-485
communication
dedicated
monitor
(hexadecimal)
Modbus-
RTU
real
time
monitor
Minus (-)
display
Description
