Mitsubishi FR-A800

(T) Multi-Function Input Terminal Parameters
416
PARAMETERS
Relationship between the analog input terminal function and the
calibration parameter
• Calibration parameter according to the terminal 1 function
• Calibration parameter according to the terminal 4 function
To change the frequency for the maximum analog input (Pr.125, Pr.126)
• To change only the frequency setting (gain) for the maximum analog input voltage (current), set Pr.125 (Pr.126).
(C2 (Pr.902) to C7 (Pr.905) settings do not need to be changed.)
Pr.868
Setting
Terminal function
Calibration parameter
Bias setting Gain setting
0
(initial
value)
Frequency (speed) setting
auxiliary
C2 (Pr.902) Terminal 2 frequency setting bias
frequency
C3 (Pr.902) Terminal 2 frequency setting bias
C5 (Pr.904) Terminal 4 frequency setting bias
frequency
C6 (Pr.904) Terminal 4 frequency setting bias
Pr.125 Terminal 2 frequency setting gain
frequency
C4 (Pr.903) Terminal 2 frequency setting
gain
Pr.126 Terminal 4 frequency setting gain
frequency
C7 (Pr.905) Terminal 4 frequency setting
gain
1 Magnetic flux command
C16 (Pr.919) Terminal 1 bias command
(torque)
C17 (Pr.919) Terminal 1 bias (torque)
C18 (Pr.920) Terminal 1 gain command
(torque)
C19 (Pr.920) Terminal 1 gain (torque)
2
Regenerative driving
torque limit
C16 (Pr.919) Terminal 1 bias command
(torque)
C17 (Pr.919) Terminal 1 bias (torque)
C18 (Pr.920) Terminal 1 gain command
(torque)
C19 (Pr.920) Terminal 1 gain (torque)
3 Torque command
4
Stall prevention operation
level

/torque limit/torque
command
5
Forward/reverse rotation
speed limit
C12 (Pr.917) Terminal 1 bias frequency
(speed)
C13 (Pr.917) Terminal 1 bias (speed)
C14 (Pr.918) Terminal 1 gain frequency
(speed)
C15 (Pr.918) Terminal 1 gain (speed)
6 Torque bias input
C16 (Pr.919) Terminal 1 bias command
(torque)
C17 (Pr.919) Terminal 1 bias (torque)
C18 (Pr.920) Terminal 1 gain command
(torque)
C19 (Pr.920) Terminal 1 gain (torque)
9999 No function 
Pr.858
setting
Terminal function
Calibration parameter
Bias setting Gain setting
0
(initial
value)
Frequency command
C5 (Pr.904) Terminal 4 frequency setting
bias frequency
C6 (Pr.904) Terminal 4 frequency setting
bias
Pr.126 Terminal 4 frequency setting gain
frequency
C7 (Pr.905) Terminal 4 frequency setting
gain
1 Magnetic flux command
C38 (Pr.932) Terminal 4 bias command
(torque)
C39 (Pr.932) Terminal 4 bias (torque)
C40 (Pr.933) Terminal 4 gain command
(torque)
C41 (Pr.933) Terminal 4 gain (torque)
4
Stall prevention operation
level

/torque limit
C38 (Pr.932) Terminal 4 bias command
(torque)
C39 (Pr.932) Terminal 4 bias (torque)
C40 (Pr.933) Terminal 4 gain command
(torque)
C41 (Pr.933) Terminal 4 gain (torque)
9999 No function 
 Perform stall prevention operation level bias/gain adjustment by using the Pr.148 Stall prevention level at 0 V input and Pr.149 Stall
prevention level at 10 V input.
