(T) Multi-Function Input Terminal Parameters
PARAMETERS
435
5
GROUP
T
• When the RT (X9) signal is ON, the following second (third) functions are selected at the same time.
NOTE
• RT signal is assigned to the terminal RT in the initial status. Set "3" in any of Pr.178 to Pr.189 (input terminal function
selection) to assign the RT signal to another terminal.
• When both the RT signal and X9 signal are ON, the X9 signal (third function) is prioritized.
• Changing the terminal assignment using
Pr.178 to Pr.189 (input terminal function selection) may affect the other functions.
Set parameters after confirming the function of each terminal.
???????
Parameters referred to
Pr.178 to Pr.189 (input terminal function selection) page 430
Function
First function
Parameter number
Second function
Parameter number
Third function
Parameter number
Refer to
page
Torque boost Pr.0 Pr.46 Pr.112 597
Base frequency Pr.3 Pr.47 Pr.113 598
Acceleration time Pr.7 Pr.44 Pr.110 285
Deceleration time Pr.8 Pr.44, Pr.45 Pr.110, Pr.111 285
Electronic thermal O/L
relay
Pr.9 Pr.51

331
Free thermal Pr.600 to Pr.604 Pr.692 to Pr.696

Motor permissible load
level

Pr.607 Pr.608  331
Stall prevention Pr.22 Pr.48, Pr.49 Pr.114, Pr.115 348
Applicable motor
 Pr.71 Pr.450  438
Motor constant

Pr.80 to Pr.84, Pr.89 to Pr.94,
Pr.298, Pr.702, Pr.706,
Pr.707, Pr.711, Pr.712,
Pr.717, Pr.721, Pr.724,
Pr.725, Pr.859
Pr.453 to Pr.457, Pr.560, Pr.569,
Pr.458 to Pr.462, Pr.738 to Pr.747,
Pr.860
 442, 452
Offline auto tuning
 Pr.96 Pr.463  442, 452
Online auto tuning
 Pr.95 Pr.574  460
PID control Pr.127 to Pr.134 Pr.753 to Pr.758
 501
PID Pre-charge
function
Pr.760 to Pr.764 Pr.765 to Pr.769
 517
Brake sequence

Pr.278 to Pr.285, Pr.639,
Pr.640
Pr.641 to Pr.648, Pr.650, Pr.651
 473
Low-speed range
torque characteristics

Pr.788 Pr.747  176
Motor control method

Pr.800 Pr.451  164
Speed control gain Pr.820, Pr.821 Pr.830, Pr.831
 192
Analog input filter Pr.822, Pr.826 Pr.832, Pr.836
 413
Speed detection filter Pr.823 Pr.833
 254
Torque control gain Pr.824, Pr.825 Pr.834, Pr.835
 225
Torque detection filter Pr.827 Pr.837
 254
 The function can be changed by switching the RT signal ON/OFF while the inverter is stopped. If a signal is switched during operation, the
operation method changes after the inverter stops. (Pr.450 9999)
 When the RT signal is OFF, the first function is selected and when it is ON, the second function is selected.
