Raisecom ISCOM2600G-HI (A) Series User Manual

Raisecom
ISCOM2600G-HI (A) Series Configuration Guide
1 Basic configurations
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
25

The device is started for the first time.

A system file is damaged.

The card is started improperly.
Before upgrading system software through BootROM, you should establish a TFTP
environment, and use the PC as the TFTP server and the ISCOM2600G-HI series switch as
the client. Basic requirements are as below.

Configure the TFTP server. Ensure that the TFTP server is available.

Configure the IP address of the TFTP server; keep it in the same network segment with
that of the ISCOM2600G-HI series switch.

Connect the Ethernet interface on the TFTP server to the SNMP interface on the
ISCOM2600G-HI series switch. The default IP address of the SNMP interface is
192.168.0.1 by default.
Upgrade system software through BootROM for the ISCOM2600G-HI series switch as below.
Step
Operation
1
Log in to the ISCOM2600G-HI series switch through serial interface as the
administrator, enter Privileged EXEC mode, and restart the ISCOM2600G-HI
series switch with the reboot command.
Raisecom#reboot
2
When the system successfully loads the big BootROM, and it displays "Press
space to enter big boot menu", press Space bar to enter the interface starting with
[raisecom]. The command list is displayed as below:
BOOT
**************************************************
t: Update system from tftp.
m: Update boot from tftp.
b: Boot system from flash.
e: Erase bootline para.
s: Select system image to boot.
p: Password setting.
r: Reboot.
?/h: Help menu.
[Raisecom]:
