Water Management functionality 18 Operations
Item Explanation
600.
6
Settings tab
7
Edit Line tab
8
Info tab
9
Distance: The selected location's distance from the start of the section line.
10
OKbutton: Tap to save any changes to the design.
Design a section line
After you create survey lines, use design screen to create designs for installing tile or cleaning ditches
along those lines.
1.
At the Run screen, tap to open the WM-Drain panel.
2. Go to the Design tab of the panel.
3. From the Section list, select the section line that you want to design and tap Edit Design.
4.
If required, tap Select Closest. This enables you to select the line that is closest to you. If there is
more than one line within 10 m of your current position, the Select Closest Section Line screen
displays.The line that is calculated as being closest to you is highlighted. The section line
number and pipe type are shown. Choose the line you want and tap OK. The system displays
the Design screen.
5.
At the Design screen, from the Section list choose the section line you want to design.
Setting at Top of Screen Explanation
Section Selection
Auto: The nearest section line is automatically selected.
Manual:Manually select a section from the list.
Rename
button Tap to rename the section name.
Direction
The design screen shows the outlet at the left side of the
screen and runs the design uphill to the right side of the
screen. The direction of the profile is defined by the
direction that it was surveyed. If your survey profile is
displayed the other way, switch the option shown in the
Direction list to the other option in the list.
Options are:
ll Outlet at Survey Start
l
Outlet at Survey End
460 FM-1000 Integrated Display User Guide Version 9.25, Revision B
