3 Basic settings Basic system settings
Status Item Explanation
arrow, which means that the blade needs to move up to reach
the Target Height.
P Design Height Height the primary blade will attempt to reach. This is the Design
Height ± the Offset. When the blade reaches the Target Height, the
arrows turn green.
P Design Slope When using the Autoslope leveling model, this displays the design
slope with respect to the current location along the section line.
P Distance Traveled Distance traveled since Auto mode was enabled. (For use with
FieldLevel II Point to Slope mode). The d
P East Distance that the primary blade receiver is to the east of the field
origin point (a negative number means the receiver is to the west of
the field origin point)
P GPS Status GPS correction type that the primary blade GPS receiver is currently
using
P H Error (Horizontal error) An estimation of the level of precision of the
primary blade GPS position in 2 dimensions
P HDOP Horizontal Dilution of Precision of the primary blade receiver: A
measure of accuracy based on the geometry of the satellites in the
sky. If the satellites are near each other in the sky, the HDOP is
higher (lower is better).
P Heading Current heading of the primary blade, in degrees, from direct north
P Latitude Primary blade's current latitude
P Longitude Primary blade's current longitude
P Network ID RTK network ID of the primary blade receiver's corrections
P North Distance that the primary blade receiver is to the north of the field
origin point (a negative number means the receiver is to the south
of the field origin point)
P Offset Separate plane that is parallel to the design plane. The offset if
defined by a single measurement, which is the height that the offset
plane is from the design plane.
P Offset X Relative Position X offset from the master benchmark
P Offset Y Relative Position Y offset from the master benchmark
P Satellites Number of satellites the system is currently being received by the
FieldLevel II GPS receiver
Version 9.25, Revision B FM-1000 Integrated Display User Guide 77
