Xerox WorkCentre 6505 Service Manual

I – 6 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Index
Motor
Automatic Document Feeder (ADF), 2-65, 2-69
feed drive assembly, 2-36
main drive assembly, 2-36
sub drive assembly, 2-36
toner, 2-34
Motor Test
ADF, 4-65
FB (flatbed), 4-64
N
Network
settings, 4-81
Network connector
location, SFP, 1-6
MFP, 1-7
No Paper Actuator
part number, 9-58
No Paper Sensor
Optional Feeder
removal, 8-186
removal, 8-79
tray, 2-22
troubleshooting, Tray 1, 4-21
No Paper Sensor Actuator
Optional Feeder, removal, 8-188
removal, 8-84
NVRAM
initializing, 6-6
location (MFP), 2-42
location (SFP), 2-40
O
Operation Modes, 2-43
Option Drive Clutch
part number, 9-54
removal, 8-174
Option Harness, MFP
part number, 9-17
Option Harness, SFP
part number, 9-17
Optional Feeder, 1-13, 2-24
Board removal, 8-173
cassette assy. part number, 9-60
Chute Cover removal, 8-170
clutch kit part number, 9-54
components, 2-24
disassembly, 8-167 to 8-190
drive clutch, 2-24
Drive Clutch and Bearing removal, 8-174
drive transmission, 2-58
Feed Gear Kit
part number, 9-54
removal, 8-178
Feed Gear removal, 8-175
feed motor, 2-24
part number, 9-54
removal, 8-177
feed roller
operation, 2-24
part number, 9-58
removal, 8-182
feed solenoid, 2-24
operation, 2-24
removal, 8-176
feeder board, 2-24
part number, 9-54
Front Cover removal, 8-168
Left Side Cover removal, 8-169
no paper sensor, 2-24
part number, 9-58
removal, 8-186
No Paper Sensor removal, 8-186
Optional Feeder Harness
part number, 9-56
removal, 8-179
paper path sensor, 2-24
removal, 8-187
part number, 9-52
Rear Cover removal, 8-171
registration bearing
part number, 9-56
Registration Input Actuator, 8-185
registration input actuator
part number, 9-58
Registration Roller Bearing removal, 8-181
Registration Roller removal, 8-183
registration sensor
part number, 9-58
removal, 8-187
removal, 8-167
Right Side Cover removal, 8-172
separator holder
part number, 9-60
removal, 8-190
Outer Pole Cover removal, MFP, 8-39
Output tray, 1-2
Output Tray Extension, SFP
part number, 9-6
removal, 8-16
http://www.manuals4you.com

Xerox WorkCentre 6505 Specifications

General

Print Technology	Laser
Copy Resolution	Up to 600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	35 sheets
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory	256 MB
Fax Transmission Speed	33.6 kbps
Monthly Duty Cycle	40, 000 pages
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Maximum Paper Size	8.5 x 14 in
Operating System Compatibility	Windows, Mac, Linux
Print Resolution	Up to 1200 x 2400 dpi
