8.3.1.14 STOP Mode Configuration Register (ME_STOP_MC)
This register configures system behavior during STOP mode. Please refer to Table 8-11 for details.
NOTE
Byte and half-word write accesses are not allowed to this register.
8.3.1.15 STANDBY Mode Configuration Register (ME_STANDBY_MC)
This register configures system behavior during STANDBY mode. Please refer to Table 8-11 for details.
Address 0xC3FD_C048 Access: Supervisor read/write
0123456789101112131415
R00000000
PDO
00
MVRON
DFLAON CFLAON
W
Reset0000000000010101
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
000000000
FMPLLON
FXOSCON
FIRCON
SYSCLK
W
Reset0000000000010000
Figure 8-15. STOP Mode Configuration Register (ME_STOP_MC)
Address 0xC3FD_C054 Access: Supervisor read/write
0123456789101112131415
R
00000000PDO00
MVRON
DFLAON CFLAON
W
Reset0000000010000101
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
000000000
FMPLLON
FXOSCON
FIRCON
SYSCLK
W
Reset0000000000011111
Figure 8-16. STANDBY Mode Configuration Register (ME_STANDBY_MC)
