8.3.1.12 RUN0…3 Mode Configuration Registers (ME_RUN0…3_MC)
This register configures system behavior during RUN0…3 modes. Please refer to Table 8-11 for details.
NOTE
Byte and half-word write accesses are not allowed to this register.
8.3.1.13 HALT Mode Configuration Register (ME_HALT_MC)
This register configures system behavior during HALT mode. Please refer to Table 8-11 for details.
NOTE
Byte and half-word write accesses are not allowed to this register.
Address 0xC3FD_C030 - 0xC3FD_C03C Access: Supervisor read/write
0123456789101112131415
R
00000000PDO00
MVRON
DFLAON CFLAON
W
Reset0000000000011111
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R
000000000
FMPLLON
FXOSCON
FIRCON
SYSCLK
W
Reset0000000000010000
Figure 8-13. RUN0…3 Mode Configuration Registers (ME_RUN0…3_MC)
Address 0xC3FD_C040 Access: Supervisor read/write
0123456789101112131415
R00000000PDO00
MVRON
DFLAON CFLAON
W
Reset0000000000011010
16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
R000000000
FMPLLON
FXOSCON
FIRCON
SYSCLK
W
Reset0000000000010000
Figure 8-14. HALT Mode Configuration Register (ME_HALT_MC)
