■ Target Data
Selects the data to copy from the Data Log data.
Example: When Start Number is 2 and End Number is 4, data 2 to 4 is the copy target.
■ Trigger Condition
Selects the condition to start copying.
Sampling Time: Select this check box to copy the sampling time data from the Data Log data. When this
check box is selected, values of device addresses are copied in order from the data for
data number 1.
Value of Device Address: Select this check box to copy the value of device address from the Data Log data.
Data Number: Selects the specification method for the data number of the value to copy.
Value: Uses a constant value.
Device Address: Uses a value of device address.
Start Number: Of the data to copy, specifies the data number of the
data to start copying.
If you select Value, specify the data number (1 to 128).
If you select Device Address, specify the source device
address. You can only specify an internal device. For the
device address configuration procedure, refer to Chapter
2 “5.1 Device Address Settings” on page 2-70.
When the Sampling Time check box is selected, the
data number is 1. This cannot be changed.
End Number: Of the data to copy, specifies the data number of the
data to end copying.
If you select Value, specify the data number (1 to 128).
If you select Device Address, specify the source device
address. You can only specify an internal device. For the
device address configuration procedure, refer to Chapter
2 “5.1 Device Address Settings” on page 2-70.
Start No. End No.
Data No.: 1 2 3 4 5
↓↓↓↓↓
Sampling Time Data 1 Data 2 Data 3 Data 4 Data 5
10/01/2011 12:34:56 100 60 240 60 240
10/02/2011 03:45:12 200 80 450 80 450
Copy target
Always: Copies each time the data is updated.
Device Address: Specifies the device address that triggers the start of copying the data. Copies the data when
the value of the specified device address changes from 0 to 1.
For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings”
on page 2-70.
