WindO/I-NV4 User’s Manual 18-7
2 Recipe Function Configuration Procedure
18
Recipe Function
14
Enter the file name for the recipe file in File Name.
The default file name is “RCPn.CSV”. (n: 4 digit sequential number)
To change the file name, enter a new file name. The maximum number is 120 characters (including the extension).
The file is overwritten when there is a recipe file with the same name on the external memory device.
15
Select the operation using the data for the recipe under Trigger Setting.
This option is set by block.
■ Read/Write
Save batch read values of device addresses to the external memory device as a recipe file or write them to device
addresses as recipe values.
This option can only be configured when External Memory Device is selected under Access to.
■ Read-only
Save batch read values of device addresses to the external memory device as a recipe file.
This option can only be configured when External Memory Device is selected under Access to.
■ Write-only
Write recipe values to device addresses.
If you select Write-only, proceed to step
17
.
16
Specify the device address that triggers batch reading values of device addresses and saving them to the external
memory device as a recipe file in Read Trigger.
This option is set by block.
Click to display the Tag Editor.
For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-70.
This option can only be configured when Read/Write or Read-only is selected under Trigger Setting.
If you selected Read-only, proceed to step
18
.
17
Specify the device address that triggers batch writing recipe values to device addresses in Write Trigger.
This option is set by block.
Click to display the Tag Editor.
For the device address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-70.
This option can only be configured when Read/Write or Write-only is selected under Trigger Setting.
18
Click OK to close the Individual Settings dialog box.
You are returned to the Recipe Settings dialog box.
19
Repeat steps 3 through
18
to register data for the recipe to all the used channels.
20
Click OK.
The Recipe Settings dialog box closes.
For details on how to create and edit the data for recipes, refer to “4 Creating and Deleting Data for Recipes” on page
18-14.
