2 Editing and Management of the Script
20-8 WindO/I-NV4 User’s Manual
■ Select
The highlighted script in the script list is selected and the Script Manager is closed.
●
Using registered script on another project
To use the script registered in Script Manager on another project, save it as a file, and then import it to a project.
Saving registered script as a file
1 On the Configuration tab, in the Manager group, click Script Manager.
Script Manager opens.
2 Select the script in Script List, and then click Export.
The Browse For Folder dialog box is displayed.
The contents executed by the script used in the project can be checked with the debug function of the
simulator. For details, refer to Chapter 26 “3.5 Script Debugger” on page 26-15.
To export multiple scripts, select all scripts to export. To select multiple scripts, press and hold SHIFT or
CTRL while you click the specific items.
