3 Sound Settings Dialog Box
21-8 WindO/I-NV4 User’s Manual
■ Change Volume Level
Adjust the volume (0 to 31) of sound files and movie files played by the MICRO/I.
The volume changes according to the value of the specified Device Address.
The sound is muted when the Device Address value is 0, and the volume is maximum when the value is 31 or out of range.
Enter the Device Address in the text box or click to specify the address in the displayed Tag Editor. For the device
address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-70.
■ Enable Mute
Mute the volume of sound files and movie files played by the MICRO/I.
When the value of the specified Device Address is 1, the sound is muted.
When the sound is muted while a sound file is playing, it continues playing without making a sound.
Enter the Device Address in the text box or click to specify the address in the displayed Tag Editor. For the device
address configuration procedure, refer to Chapter 2 “5.1 Device Address Settings” on page 2-70.
●
Individual Settings Dialog Box
Register or change the settings of the selected ID.
■ ID
Shows the Sound ID (1 to 1024) of the sound file to be played.
If the Individual Settings dialog box is opened with multiple IDs selected in Settings, ID number will not be
displayed.
■ File Name
Specify the sound file.
Click the button to display the Open dialog box. Then specify a sound file with the Open dialog box.
If the Individual Settings dialog box is opened with multiple IDs selected in Settings, File Name will not be
displayed.
■ Save To
Select the location to save the sound file to as Internal Memory or External Memory Device
*1
.
*1 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G-V and HG4G/3G
*2 HG5G/4G/3G-V, HG4G/3G only
*2
When the Change Volume Level check box is cleared, MICRO/I plays sound files and movie files at
maximum volume.
*2
To Next Page
