WindO/I-NV4 User’s Manual 3-17
5 User Communication
3
Communication
22
Select the condition for being ready to receive data in Trigger Type under Trigger Condition from the following.
■ Always Enabled
The device is always ready to receive data.
■ While ON
Ready to receive data when the value of device address is 1.
Specify the bit device or the bit number of the word device as the condition.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
■ While OFF
Ready to receive data when the value of device address is 0.
Specify the bit device or the bit number of the word device as the condition.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
■ While satisfying the condition
Ready to receive data while a condition is satisfied.
Specify the conditional expression in Condition and select the type of data handled by the conditional expression in
Data Type.
Click to display the Trigger Condition Settings dialog box. For the conditional expressions configuration
procedure, refer to Chapter 2 “5.2 Setting Conditional Expressions” on page 2-73.
For details on data types, refer to Chapter 2 “1.1 Available Data” on page 2-1.
23
Specify the bit device or the bit number of the word device for reporting that data receiving was successfully
completed in Completed Device Address under Detail.
Click to display the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
If the value of Completed Device Address automatically is not set to 0 after it is set to 1, select the Not Clear
Completed Device Address automatically check box.
24
Specify the destination word device for the received data size and error information in Status Device Address under
Detail.
Click to display the
Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
25
Enter a comment for receive command in Comment under Detail.
The maximum number is 40 characters.
To Next Page
