WindO/I-NV4 User’s Manual 24-3

1 Communicating with the MICRO/I

Online Function

• Display the information about the system software and project data of the MICRO/I.

• Edit a project data in WindO/I-NV4 while checking MICRO/I operation by displaying and changing values of device

addresses and switching screens using the monitor function.

Computer

MICRO/I

System

Information

Computer

External device

Screen monitor

LDR1= 0 130

MICRO/I

130

Computer

Switches to Base Screen 2.

MICRO/I

Full

Tank1

130

External device

Base Screen 1

Base Screen 2

For details about monitor function, refer to Chapter 25 “1 Monitoring with WindO/I-NV4” on page 25-1.
