6 System Information

24-34 WindO/I-NV4 User’s Manual

Communication Driver Information Dialog Box

Checks the communication driver configured in the project downloaded to the MICRO/I.

■ External Device Communication 1 to 4

HG3G

HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T

HG4G HG1G HG1P

HG2J-7U

HG3G

HG2G-5FHG5G-V HG4G-V HG3G-V HG2G-V HG2G-5T

HG4G HG1G HG1P

HG2J-7U

Manufacturer: Displays the manufacturer of the external device.

Communication Driver: Displays the communication driver.

Communicate Driver Version: Displays the communication driver version.
