1 Monitoring with WindO/I-NV4

25-14 WindO/I-NV4 User’s Manual

4 Click the device address to import.

5 Click OK.

If there is an already registered device address on the Custom Monitor, an overwrite confirmation message is

displayed.

• Click Yes to overwrite the device address displayed in the confirmation message.

• Click Yes To All to overwrite all the device addresses.

• Click No to display the next confirmation message without overwriting the device address displayed in the

confirmation message.

• Click Cancel to stop importing device addresses.

The device address is added to Monitor.

To select multiple items of text, press and hold SHIFT or CTRL while you click the specific items.
