1 Web Server Function
28-8 WindO/I-NV4 User’s Manual
*1 HG2J-7U only
*2 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
Display item Description
Project
Information
Project Name
Shows the project name.
(When characters other than alphanumeric characters are included on
the English page, the project name is shown as “-Wrong Strings-”.)
Author Shows the project author.
Date Modified (m/d/y h:m:s)
Shows the project’s last modified date/time. The displayed date/time is
Greenwich Mean Time (GMT).
Installed Font
*2
Shows the extension fonts installed in the MICRO/I.
External
Device
Communi-
cation 1 to 4
Interface Shows the communication interface.
Manufacturer Shows the external device manufacturer name.
Communication Driver Name
Shows the communication driver name.
Communication Driver Version
Shows the communication driver version.
(Parameter unique to driver - 1)
The four items below the driver version show each driver’s unique
settings. The item names differ according to the drivers.
(Parameter unique to driver - 2)
(Parameter unique to driver - 3)
(Parameter unique to driver - 4)
Serial Interface
Shows the serial interface used as the External Device Communication 1 to 4.
Baud Rate [bps] Shows the speed of the External Device Communication 1 to 4.
Data Bits Shows the data length of the External Device Communication 1 to 4.
Stop Bits Shows the stop bits of the External Device Communication 1 to 4.
Parity Shows the parity of the External Device Communication 1 to 4.
Flow Control
Shows the flow control method of the External Device Communication 1 to 4.
Retry Cycles
Shows the number of times to retry communication before displaying a
communication error of the External Device Communication 1 to 4.
Time Out [msec]
Shows the response waiting time from the External Device
Communication 1 to 4.
Transmission Wait [msec]
Shows the transmission interval for a communication command of the
External Device Communication 1 to 4.
O/I Link
Baud Rate [bps] Shows the O/I link communication speed.
O/I Link Station Shows the O/I link master station or slave station number.
Slave Registration Settings
Shows the slave registration setting register for the O/I link
communication master.
Slave Online Status
Shows the slave online information register for the O/I link
communication master.
Ethernet
IP Address Shows the IP address.
Subnet Mask Shows the subnet mask.
Gateway Shows the default gateway address.
MAC Address Shows the Ethernet MAC address.
Wireless
LAN
*1
IP Address Shows the IP address of the wireless LAN.
Subnet Mask Shows the subnet mask of the wireless LAN.
MAC Address Shows the Ethernet MAC address of the wireless LAN.
System
Operation
Default Screen Number Shows the screen number displayed when MICRO/I starts running.
Screen Number Format Shows the depiction method for the displayed screen number.
Start Time [sec]
Shows the time until starting communication with the external device.
Auto Backlight OFF [min] Shows the time for the backlight to turn off automatically.
Flashing Cycle [sec]
Shows the flashing speed for parts and draw objects with the blinking
attribute.
Touch Sound Shows On or Off for the touch panel confirmation sound.
Menu Language Shows the system screen’s display language.
• The contents of the display items on the system detailed information page are the values set on the
Project Settings dialog box displayed by clicking Project under System Setup on the Configuration tab
in WindO/I-NV4.
• For details on the item of the External Device Communication 1 to 4, refer to the WindO/I-NV4 External
Device Setup Manual.
