4 E-mail Function
28-54 WindO/I-NV4 User’s Manual
■ Trigger Condition
Set the trigger conditions for sending e-mail.
Trigger Type: A condition for sending e-mail is selected from the following.
Rising-edge: An e-mail is sent when the value of device address changes from 0 to 1.
Falling-edge: An e-mail is sent when the value of device address changes from 1 to 0.
Satisfy the condition:
An e-mail is sent when the condition changes from not satisfied to satisfied.
Data Type: Select the data type handled by the conditional expression.
Can only be set if Satisfy the condition is selected as Trigger Type.
For details, refer to Chapter 2 “1.1 Available Data” on page 2-1.
Device Address: Specifies the bit device or the bit number of the word device to serve as condition. You can only
specify the internal device.
Can only be set if Rising-edge or Falling-edge is selected as Trigger Type. Click to display
the Tag Editor. For the device address configuration procedure, refer to Chapter 2 “5.1 Device
Address Settings” on page 2-70.
Condition: Sets the condition formula.
Can only be set if Satisfy the condition is selected as Trigger Type. Click to display the
Trigger Condition Settings dialog box. For the conditional expressions configuration procedure, refer
to Chapter 2 “5.2 Setting Conditional Expressions” on page 2-73.
Value of Device Address
1
0
Action
Execution Execution Execution
1
0
Value of Device Address
Action
Execution Execution
Action
Execution
Condition
Satisfied
Not satisfied
Execution Execution
