2 PLC Program Transfer Function

29-20 WindO/I-NV4 User’s Manual

● Upload

1 Insert an external memory device

in the MICRO/I.

2 Press the Key Button or Multi-Button or execute the Multi-Command configured with Upload PLC Program under

Data Transfer on the Key Browser.

*1 Only USB flash drive for HG2J-7U, HG2G-5T and HG1G/1P

PLC

MICRO/I

USB flash drive

SD memory card

External Memory Device
