2 PLC Program Transfer Function
29-28 WindO/I-NV4 User’s Manual
10
Specify the MICRO/I communication port and the slave number or the External Device ID, and then press YES.
Specify the Slave Number when selecting serial interface as the MICRO/I communication port, and specify the
External Device ID when selecting Ethernet interface.
The PLC program upload starts.
When the upload finishes, the results are displayed.
11
Press Ack to close the screen.
You are returned to the Top Page of System Mode.
YES NO
Copy This File ?
PLC.ZLD
Comm.I/F:
Slave Number:
Communication port
Slave number or
External Device ID
000
SERIAL 1
• “PLC.ZLD” is displayed in the confirmation message, but the ZLD Project File name after uploading is
“Model name_Port number_Station number_Year month day hours minutes seconds + File extension
(.zld)”.
• When downloading a ZLD Project File to a PLC configured with a password, the PLC password screen is
displayed. Enter the password.
Upload PLC Program
Function
The following function completed
Result
Ack
