WindO/I-NV4 User’s Manual 30-15
3 Analog I/O Modules
30
Expansion Modules
■ Signal Type
The signal type that can be set differs according to the analog I/O module model. Select the analog I/O module that
corresponds to the user application and set the signal type. The signal type is the type of analog input to measure.
There are 24 signal types for the analog inputs, which are detailed as follows.
YES: Supported, NO: Not supported
*1 Channels that are set to unused are not scanned.
The circuit is setup the same as when 0 to 10V DC is selected as Signal Type.
0 is always stored in the analog data storage data registers for channels that are set to unused.
*2 For details, refer to “ PTC Thermistor (Threshold)” on page 30-21.
Signal Type
FC6A-J2C1
FC6A-J2C4
FC6A-J4A1
FC6A-J4A4
FC6A-J8A1
FC6A-J8A4
FC6A-J4CN1
FC6A-J4CN4
FC6A-J4CH1Y
FC6A-J4CH4Y
FC6A-J8CU1
FC6A-J8CU4
FC6A-L06A1
FC6A-L06A4
FC6A-L03CN1
FC6A-L03CN4
Unused
*1
YES YES YES YES YES YES YES YES
0 to 10V DC YES YES YES YES NO NO YES YES
-10 to +10V
DC
YES YES YES YES NO NO YES YES
0 to 20mA DC YES YES YES YES NO NO YES YES
4 to 20mA DC YES YES YES YES NO NO YES YES
Type K
thermocouple
NO NO NO YES YES YES NO YES
Type J
thermocouple
NO NO NO YES YES YES NO YES
Type R
thermocouple
NO NO NO YES YES YES NO YES
Type S
thermocouple
NO NO NO YES YES YES NO YES
Type B
thermocouple
NO NO NO YES YES YES NO YES
Type E
thermocouple
NO NO NO YES YES YES NO YES
Type T
thermocouple
NO NO NO YES YES YES NO YES
Type N
thermocouple
NO NO NO YES YES YES NO YES
Type C
thermocouple
NO NO NO YES YES YES NO YES
Pt100 NO NO NO YES NO NO NO YES
Pt1000 NO NO NO YES NO NO NO YES
Ni100 NO NO NO YES NO NO NO YES
Ni1000 NO NO NO YES NO NO NO YES
NTC
Thermistor
NO NO NO NO NO YES NO NO
PTC
Thermistor
NO NO NO NO NO YES NO NO
PTC
Thermistor
(threshold)
*2
NO NO NO NO NO YES NO NO
Ohm meter NO NO NO NO NO YES NO NO
Expansion 0 to
20mA DC
NO NO YES NO NO NO NO NO
Expansion 4 to
20mA DC
NO NO YES NO NO NO NO NO
To Next Page
