5 User Communication
3-50 WindO/I-NV4 User’s Manual
Constant (Hexadecimal)
The hexadecimal data is sent without being converted.
Use this setting to send a control code of ASCII data (00h to 1Fh).
This can be configured only when TXD or Inching is selected as Type on the Command Settings dialog box, and
Constant (Hexadecimal) is selected under Type on the Data Settings dialog box.
â– Data
Enter hexadecimal data to be transmitted (1 to 1,500 bytes).
Example: Constant (Hexadecimal) for transmission command data
When the trigger condition is satisfied, 1234h is transmitted in the order 12h and 34h.
Item Setting
Data 1234
1234h
No
conversion
12h
Transmission data
Data
34h
Order of transmission
