WindO/I-NV4 User’s Manual 3-49
5 User Communication
3
Communication
● Transmission (TXD) Command
Constant (Character)
The character data is sent without being converted.
This can be configured only when TXD or Inching is selected as Type on the Command Settings dialog box, and
Constant (Character) is selected under Type on the Data Settings dialog box.
■ Data
Enter character data to be transmitted (1 to 1,500 bytes). The size of a single-byte character is one byte and that of
a double-byte character is two bytes.
Example: Constant (Character) for transmission command data
When the trigger condition is satisfied, the character data is transmitted in the following order.
Item Setting
Data 1234
1234
1
(31h)
Transmission data
Data
2
(32h)
3
(33h)
4
(34h)
Order of transmission
No
conversion
To Next Page
