Page #1592 background imageLoading...
Page #1592 background image
2 Word Devices
33-8 WindO/I-NV4 User’s Manual
HMI Special Data Register (LSD)
These registers (384 points) perform the following special operations.The supported device addresses vary based on
the model.
Yes: Supported, No: Not supported, (blank): Reserved
Device
Address
Function/Part
HG2J
-7U
HG5G/
4G/3G/
2G-V
HG4G/
3G,
HG2G-
5F
HG2G
-5T,
HG1G
/1P
LSD0 to 3 Reserved
LSD4 Scan time Maximum value (msec.) Yes Yes Yes Yes
LSD5 Screen switch response time (msec.) Yes Yes Yes Yes
LSD6
Read scan communication time of External Device Communication 1 (msec.)
Yes Yes Yes Yes
LSD7 Scan counter (incremented at each scan) Yes Yes Yes Yes
LSD8 1 second counter (incremented each second) Yes Yes Yes Yes
LSD9 10 msec. counter (increments every 10 msec.) Yes Yes Yes Yes
LSD10 100 msec. counter (incremented every 100 msec.) Yes Yes Yes Yes
LSD11 200 msec. counter (incremented every 200 msec.) Yes Yes Yes Yes
LSD12 500 msec. counter (incremented every 500 msec.) Yes Yes Yes Yes
LSD13
Stores the current Year data from the MICRO/I. “Year” (4 BCD digits)
Yes Yes Yes Yes
LSD14 Stores current time data from MICRO/I. “Month” (2 BCD digits) Yes Yes Yes Yes
LSD15 Stores current time data from MICRO/I. “Day” (2 BCD digits) Yes Yes Yes Yes
LSD16 Stores current time data from MICRO/I. “Hour” (2 BCD digits) Yes Yes Yes Yes
LSD17 Stores current time data from MICRO/I. “Minute” (2 BCD digits) Yes Yes Yes Yes
LSD18 Stores current time data from MICRO/I. “Second” (2 BCD digits) Yes Yes Yes Yes
LSD19
Stores current time data from MICRO/I. Day-of-week” (1 BCD digit)
0: Sunday, 1: Monday, 2: Tuesday, 3: Wednesday, 4: Thursday,
5: Friday, 6: Saturday
Yes Yes Yes Yes
LSD20
When a value of “1” is written into this special register, the Internal
clock in MICRO/I is updated according to the data stored in LSD21-
26. It automatically resets to “0” after the update.
Yes Yes Yes Yes
LSD21
Write a “Year” value to store in the MICRO/I internal clock. (2 BCD digits)
Yes Yes Yes Yes
LSD22
Stores set value for “Month” in MICRO/I internal clock. (2 BCD digits)
Yes Yes Yes Yes
LSD23 Stores set value for “Day” in MICRO/I internal clock. (2 BCD digits) Yes Yes Yes Yes
LSD24 Stores set value for “Hour” in MICRO/I internal clock. (2 BCD digits) Yes Yes Yes Yes
LSD25
Stores set value for “Minute” in MICRO/I internal clock. (2 BCD digits)
Yes Yes Yes Yes
LSD26
Stores set value for “Second” in MICRO/I internal clock. (2 BCD digits)
Yes Yes Yes Yes
LSD27 Scan time Current value (msec.) Yes Yes Yes Yes
LSD28 Scan time Minimum value (msec.) Yes Yes Yes Yes
LSD29
Execution result of SNTP Server
0: Successfully Completed
2: Timeout error
4: Other error
Yes No No No
LSD30
Stores the elapsed time (0 to 65535 minutes) from the point when
MICRO/I obtained the time from the SNTP server until now.
The value resets and elapsed time starts getting stored once
MICRO/I successfully obtain current time from the SNTP server. In
case MICRO/I fails to obtain the current time, the elapsed time will
not reset and keep on getting stored until successfully obtaining the
time.
Yes No No No
LSD31 Stores the currently displayed screen number. Yes Yes Yes Yes
LSD32
Set a value (in reference to a Base Screen number you want to
switch to) and it will automatically switch to a specified Base Screen
number.
The data type is determined by the data type specified in Screen
Number Format on the Project Setting dialog box.
Yes Yes Yes Yes
