WindO/I-NV4 User’s Manual 33-9
2 Word Devices
33
Internal Devices
*5 USB flash drive inserted in USB2 for HG2J-7U
*6 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F
*7 HG2J-7U, HG5G/4G/3G/2G-V, HG4G/3G , HG2G-5F only
*8 HG2G-5T, HG1G/1P only
LSD33
USB flash drive error status
0: Normal
1: A write occurred when the USB flash drive was not inserted or
when an incompatible USB flash drive was inserted
2: Format error
3: Access error, Insufficient memory in USB flash drive or Reading
or writing failure
4: Unsuccessful read of picture data
No No No Yes
LSD34
USB flash drive
*5
free memory capacity Lower word (Kbytes)
Yes Yes Yes Yes
LSD35
USB flash drive
*5
free memory capacity Upper word (Kbytes)
Yes Yes Yes Yes
LSD36
USB flash drive
*5
total memory capacity Lower word (Kbytes)
Yes Yes Yes Yes
LSD37
USB flash drive
*5
total memory capacity Upper word (Kbytes)
Yes Yes Yes Yes
LSD38 to 41 Reserved
LSD42
External memory device
*6
error status
0: Normal
1: A write occurred when the USB flash drive was not inserted or
when an incompatible USB flash drive was inserted
2: Format error
3: Access error, Insufficient memory in Memory card or Reading or
writing failure.
4: Unsuccessful read of picture data
Yes Yes Yes No
LSD43
External memory device
*6
free memory capacity Lower word (Kbytes)
Yes Yes Yes No
LSD44
External memory device
*6
free memory capacity Upper word (Kbytes)
Yes Yes Yes No
LSD45
External memory device
*6
total memory capacity Lower word (Kbytes)
Yes Yes Yes No
LSD46
External memory device
*6
total memory capacity Upper word (Kbytes)
Yes Yes Yes No
LSD47 Reserved (for Communication drivers)
LSD48 Reserved
LSD49 Stores the O/I Link slave station number. (Read-only) Yes Yes Yes Yes
LSD50
The sequence value of the message number (or channel number if
the alarm function is being used) selected by the cursor in the Alarm
List Display is stored.
A value of between 1 and 1024 (allocated using ((Block No. - 1) x 16
+ bit number + 1)) is stored for the number.
Yes Yes Yes Yes
LSD51
Brightness level: -16 to 31
*7
, 0 to 31
*8
Yes Yes Yes Yes
LSD52 The ID number of the script for which the error occurred. Yes Yes Yes Yes
LSD53
Script error status
0: Normal
1: Processing error
2: Execution time over error
3: Writing count error
4: Indirect device error
5: Parameter error
6: Fixed Interval Script execution time over
7: Fixed interval execution error
For details about the Script error, refer to Chapter 20 “Types and
causes of script errors” on page 20-4.
Yes Yes Yes Yes
LSD54 Reserved (for Script)
LSD55 Reserved
LSD56
The number of lines of data from the start line to the line currently
selected with the cursor displayed in the Alarm List Display or Alarm
Log Display is stored.
Yes Yes Yes Yes
LSD57
The number of log data pieces stored in the Data Storage Area by
the alarm log function is stored. (0 to 1024)
Yes Yes Yes Yes
Device
Address
Function/Part
HG2J
-7U
HG5G/
4G/3G/
2G-V
HG4G/
3G,
HG2G-
5F
HG2G
-5T,
HG1G
/1P
